1. Equipment Description
G-tech Handheld Vibrometer, Portable Vibration Tester, Digital
Vibration Analyzer - vPod Lite provides intelligent measurements in many demanding environments.
More powerful than analog meters, the vPod Lite comes standard with
a high precision 24 bit analog / digital converter for measurement
accuracy.
The built-in microprocessor makes G-tech Handheld Vibrometer, Portable Vibration Tester, Digital
Vibration Analyzer - vPod Lite intelligent-providing the user with auto-detection accelerometer
and cabling conditions which are shown in the upper left corner of
the LCD screen, and battery power in the bottom left corner. The
vPod Lite’s easy to view backlit display make this a meter of
choice even in dark environments. Designed for your everyday
maintenance work, the vPod Lite is an affordable measurement
solution.
2. Technical Parameters:
| Item Details | Parameter Range |
| A/D converter | 24 bit |
| CPU | AID ADuC847 |
| Accelerometer sensitivity | 200mV/g typical |
| Accelerometer frequency response | 3 Hz~5kHz ±5% |
| Accelerometer resonance frequency | 30 kHz |
| Accelerometer shock limit | 5000g peak |
| Accelerometer broadband noise | 700μg |
| Displacement range | 0~1999 μm (0~78.7mil),p-p(10~1KHz BP) |
| Velocity range | 0.0~199.9 mm/s,(0.00~7.87in/sec), 0-p (10~1KHz, ISO2954, ISO10816) |
| Acceleration range | 0~19.99 g, rms (10 Hz HP) |
| Selectable units | Acceleration:g(rms),g(peak),m/s(rms),m/s2(peak)
Velocity: mm/s(rms),mm/s(peak),in/s(rms),in/s(peak)
Displacement: μm(p-p),mil(p-p) |
| Displacement accuracy | ±5%(10~1kHz) |
| Velocity accuracy | ±5%(10~1kHz) |
| Acceleration accuracy | ±5%(10~10kHz) |
| Battery indicator | Low/25%/50%/75%/full, graphical indicator |
| Sensor bias indicator | Normal/open/short, graphical indicator |
| Back light | LED back light, auto off |
| Sensor's sensitivity range | (7~1300mV/g by user input) |
| Housing rating | IP 65, with EMI protection |
| EMI protection | CE mark |
| AC output | ±2.8V |
| Power supply | 9V alkaline battery (about 40 hours operation) |
| Auto power off | 10 minutes after pressing any key |
| Display | 120*32 graphic mode LCD |
| Analog input connector | 4pin LEMO connector |
| AC output connector | 4pin LEMO connector |
| Size | 172*92*32mm (6.77*3.62*1.25inch) |
| Weight | About 300gram (0.66lb)(including battery)
|
3. Equipment Photo:
4. Main Features:
4.1 Microprocessor-based instrument
4.2 Measures vibration, acceleration, velocity and displacement
4.3 Large backlit LCD screen
4.4 Easy to operate with one button selection of unit system
(Metric, English) and vibration unit (velocity, displacement,
acceleration).
4.5 Smart display shows vibration unit, detection and battery power
4.6 Auto detects accelerometer and cabling condition
4.7 24 bit high precision A/D converter and non-linear compensation
for high accuracy
4.8 Conform to ISO 2954 and ISO 10816 standards
4.9 IP 65 rated dust and splash-proof housing
4.10 Each meter supplied with full band calibration certificate
